Model | LFP18650L-1500 |
IEC Designation | IFpR19/66 |
Nominal Voltage | 3.2V |
Nominal Capacity | 1500mAh |
Typical Capacity | 1550mAh after standard charge and standard discharge |
Minimum Capacity | 1450mAh after standard charge and standard discharge |
Standard Charge |
Constant current at 750mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤15mA |
Fast Charge |
Constant current at 1500mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤15mA |
Standard Discharge | 300mA to 2.0V |
Fast Discharge | 1500mA to 2.0V |
Maximum Continuous Charge Current |
300mA (-20℃~0℃)
750mA (0℃~15℃)
1500mA (15℃~45℃)
750mA (45℃~60℃)
|
Maximum Continuous Discharge Current | 4500mA |
Operating Temperature |
Charge -20℃ to 60℃ Discharge -40℃ to 60℃ |
Storage Temperature |
<1 year -20℃ to 25℃ <3 months -20℃ to 40℃ <30days -20℃ to 50℃ |
Typical Weight | 39g |
