Model 型号 |
LFP26650-3200 1S1P |
|
IEC Designation IEC命名 |
1IFpR27/66 |
|
Nominal Voltage 标称电压 |
3.2V |
|
Nominal Capacity 标称容量 |
3200mAh |
|
Typical Capacity 典型容量 |
3200mAh after standard charge and standard discharge 3200mAh标准充电和放电条件下 |
|
Minimum Capacity 最低容量 |
3040mAh after standard charge and standard discharge 3040mAh标准充电和放电条件下 |
|
Standard Charge 标准充电 |
Constant current at 640mA charge to 3.60V, then constant voltage at 3.60V charge till current decline to ≤64mA 640mA恒流充电至3.60V，转恒压3.60V充电至电流 ≤64mA |
|
Fast Charge 快速充电 |
Constant current at 1600mA charge to 3.60V, then constant voltage at 3.60V charge till current decline to ≤64mA 1600mA恒流充电至3.60V，转恒压 3.60V充电至电流 ≤64mA |
|
Standard Discharge 标准放电 |
640mA to 2.6V 640mA放电至2.6V |
|
Fast Discharge 快速放电 |
1600mA to 2.6V 1600mA放电至2.6V |
|
Maximum Continuous Charge Current 最大连续充电电流 |
0~10℃ 640mA 10~20℃ 1600 mA 20~60℃ 3200 mA |
|
Maximum Continuous Discharge Current 最大连续放电电流 |
3200mA |
|
Operating Temperature 操作温度 |
Charge 0℃ to 60℃ Discharge -10℃ to 70℃ |
|
Storage Temperature 储存温度 |
<1 year小于1年 -20℃ to 25℃ <3 months小于3个月 -20℃ to 40℃ <30days小于30天 -20℃ to 50℃ |
|
Typical Weight 典型重量 |
88g |
|
PCM Electrical Characteristics 保护板电气性能 |
PCM Parameters are adjustable depends on different solutions |
|
Overcharge detection voltage 过充检测电压 |
3.90±0.025V |
|
Over-discharge detection voltage 过放检测电压 |
2.00±0.050V |
|
Overcurrent detection current 过流检测电流 |
6-12A Cut load, recover after charging 卸除负载, 充电激活 |
|
Short detection condition 短路检测条件 |
Exterior short circuit 外部短路 Cut load, recover after charging 卸除负载, 充电激活 |
