Model | LFP26650L-3400 |
IEC Designation | IFpR27/66 |
Nominal Voltage | 3.2V |
Nominal Capacity | 3400mAh |
Typical Capacity | 3500mAh after standard charge and standard discharge |
Minimum Capacity | 3300mAh after standard charge and standard discharge |
Standard Charge |
Constant current at 1700mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤33mA |
Fast Charge |
Constant current at 3400mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤32mA |
Standard Discharge | 680mA to 2.0V |
Fast Discharge | 3400mA to 2.0V |
Maximum Continuous Charge Current |
680mA (-20℃~0℃) 1700mA (0℃~15℃) 3400mA (15℃~45℃) 1700mA (45℃~60℃) |
Maximum Continuous Discharge Current | 10200mA |
Operating Temperature |
Charge -20℃ to 45℃ Discharge -40℃ to 60℃ |
Storage Temperature |
<1 year -20℃ to 25℃ <3 months -20℃ to 40℃ <30days -20℃ to 50℃ |
Typical Weight | 85g |
