Model | LFP26650P-2500 |
IEC Designation | IFpR27/66 |
Nominal Voltage | 3.2V |
Nominal Capacity | 2500mAh |
Typical Capacity | 2600mAh after standard charge and standard discharge |
Minimum Capacity | 2400mAh after standard charge and standard discharge |
Standard Charge |
Constant current at 1250mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤25mA |
Fast Charge |
Constant current at 2500mA charge to 3.65V, then constant voltage at 3.65V charge till current decline to ≤25mA |
Standard Discharge | 2500mA to 2.0V |
Fast Discharge | 25000mA to 2.0V |
Maximum Continuous Charge Current |
1250mA (0~15℃)
2500mA (15~25℃)
7500mA (25~45℃)
|
Maximum Continuous Discharge Current | 37500mA |
Operating Temperature |
Charge 0℃ to 45℃ Discharge -20℃ to 60℃ |
Storage Temperature |
<1 year-20℃ to 25℃ <3 months -20℃ to 40℃ <30days -20℃ to 50℃ |
Typical Weight | 85g |
